6.400 DWT Tanker
6.400 DWT Tanker
The vessel is designed as single-screw oil/chemical tanker to carry IMO II cargoes up to 1.54 t/m3 of specific gravity. The vessel has been built for Çeksan AŞ. The vessel is driven by one MAN 7L 27/38 800rpm main engine with 4300mm diameter propeller.
Main Particular
| Loa | 107.70 m |
| Lbp | 105.80 m |
| B | 16.60 m |
| D | 8.45 m |
| d | 6.55 m |
| DWT | 6400 t |
| Main Engine | 2380 kW |
| Service Speed | 12.5 Knots |
| Cargo Capacity | 7050 |
| Cargo density | 1.54 t/m3 |
| No of Crew | 16 |
| Class | BV |
CLASS NOTATION
BV +Hull, +Machinery, Oil/Chemical Tanker, Unrestricted Navigation, ESP, AUT-UMS, Cleanship, AVM-APS, Inwater Survey, Alternate Loading / Asymmetric Loading
PROPULSION SYSTEM
2380kW @800rpm Main Engine, Dia:4300mm 4 blade Propeller
CAPACITIES
Abt.7050 m3 Cargo Tanks, abt.2x85m3 Deck Cargo/Slop Tanks
ACCOMMODATION
9 Crew Cabin with WC, 7 Officer Cabin with WC, Pilot Room, Dayrooms, Messroom, Galley, Office
